Why can the length be customized when other cable tie tags cannot?

Most cable tie RFID tags are injection-moulded in one piece, which fixes strap length at the mould. This product is modular: the ABS head (with the RFID inlay) and nylon strap are separate components, so the strap can be cut to any length from 198–728 mm without retooling.

Is the 92×28mm head large enough for a QR code?

Yes. The flat ABS surface takes a laser-printed QR code at resolution suitable for standard industrial scanners. We recommend a minimum module size of 0.8 mm, which comfortably fits a 21×21 module version with error correction level M on the 28 mm dimension.

What is HEC / R6P / M730 and when would I use them?

These are UHF chip models from Impinj and Fujitsu optimized for specific use cases — e.g., M730 supports a larger user memory bank useful for temperature log data. If you are unsure which chip fits your system, share your middleware platform and we will recommend the best match.

What is the minimum order per custom length variant?

The overall MOQ is 1,000 pcs per order. If you require multiple strap lengths in a single order, each length variant has a sub-MOQ of 500 pcs. For example, a 2,000 pc order could be split as 500 pcs × 4 different lengths.

Is tamper evidence provided with this tag?

Yes — the single-use locking mechanism means the strap cannot be loosened or removed without cutting. A cut strap is immediately visible, providing passive tamper evidence at receiving, checkpoint, or audit. For active tamper detection requiring dedicated opening tools, see our Reusable EAS RFID Cable Tie Tag.

Disposable Customizable Length RFID Cable Tie Tag

ABS + Nylon RFID cable tie with a large 92×28mm printable head and customizable strap length from 198mm to 728mm. Supports the widest range of UHF and HF chips.

Strap length customizable from 198 mm to 728 mm — standard is 448 mm, no retooling required
92 × 28 mm flat ABS head — the largest printable face in the disposable cable tie range
Widest chip selection: UHF (U8, U9, H3, H9, HEC, R6P, M730) and HF (NTAG213, F08, ICODE SLI-X)
Custom strap length, chip model, colour, laser printing, and EPC/NDEF encoding per order

Get a Quote

Disposable Customizable Length RFID Cable Tie Tag - front view

Disposable Customizable Length RFID — Features

Most cable tie RFID tags are injection-moulded as a single piece, which permanently fixes the strap length at the mould design. A procurement team managing mixed asset diameters — narrow conduit bundles, wide cable trays, large drum flanges — ends up maintaining multiple tag SKUs, each with a different strap length, creating inventory and replenishment complexity. This tag solves that by separating the head and strap into distinct components assembled at production: a single head design serves the full asset range, with strap length specified per order batch rather than per mould revision. Standardising on one head also simplifies encoding, printing, and reader compatibility across the entire deployment.

Key Features

Strap length customizable from 198 mm to 728 mm — standard is 448 mm, no retooling required
92 × 28 mm flat ABS head — the largest printable face in the disposable cable tie range
Widest chip selection: UHF (U8, U9, H3, H9, HEC, R6P, M730) and HF (NTAG213, F08, ICODE SLI-X)
Custom strap length, chip model, colour, laser printing, and EPC/NDEF encoding per order

Disposable Customizable Length RFID — Customization

Strap Length
Specify any length from 198 mm to 728 mm. Standard is 448 mm. Minimum order per length variant: 500 pcs.
Chip Selection
UHF: U8, U9, H3, H9, HEC, R6P, M730. HF: NTAG213, MIFARE F08, ICODE SLI-X. Specify frequency and chip at order.
Colour
Six standard colours in stock. Custom colours at higher MOQ.
Laser Printing
Serial numbers, barcodes (Code 128, Code 39), QR codes, or text on the 92×28 mm head face.
Pre-Encoding
EPC (UHF) or NDEF/user memory (HF) factory-written to your data format.

Disposable Customizable Length RFID — Specifications

Head Size	92 × 28 mm
Standard Total Length	448 mm (strap customizable 198–728 mm)
Material	ABS head + Nylon strap
UHF Chips	NXP U8, U9, H3, Impinj H9, HEC, R6P, M730
HF Chips	NTAG213, MIFARE F08, ICODE SLI-X
Frequency	860–960 MHz (UHF) / 13.56 MHz (HF)
Protocol	ISO 18000-6C / ISO 14443A / ISO 15693
Operating Temp	-10 °C to +65 °C
Colour Options	Black, Yellow, Red, Blue, Green, White
Customization	Custom length, laser print, silk-screen, encoding
MOQ	1,000 pcs

Disposable Customizable Length RFID — FAQ

: Most cable tie RFID tags are injection-moulded in one piece, which fixes strap length at the mould. This product is modular: the ABS head (with the RFID inlay) and nylon strap are separate components, so the strap can be cut to any length from 198–728 mm without retooling.
: Yes. The flat ABS surface takes a laser-printed QR code at resolution suitable for standard industrial scanners. We recommend a minimum module size of 0.8 mm, which comfortably fits a 21×21 module version with error correction level M on the 28 mm dimension.
: These are UHF chip models from Impinj and Fujitsu optimized for specific use cases — e.g., M730 supports a larger user memory bank useful for temperature log data. If you are unsure which chip fits your system, share your middleware platform and we will recommend the best match.
: The overall MOQ is 1,000 pcs per order. If you require multiple strap lengths in a single order, each length variant has a sub-MOQ of 500 pcs. For example, a 2,000 pc order could be split as 500 pcs × 4 different lengths.
: Yes — the single-use locking mechanism means the strap cannot be loosened or removed without cutting. A cut strap is immediately visible, providing passive tamper evidence at receiving, checkpoint, or audit. For active tamper detection requiring dedicated opening tools, see our Reusable EAS RFID Cable Tie Tag.
